MADRID - BARCELONA H.S.R.L. CONTINUITY SYSTEM FOR PREFABRICATED U-BEAMS

Project details

Technical Data

  • Site                        Length    Span
  • La Clamor Viaduct: 439.9 m 41.5 m
  • Valle del Gallo Viaduct: 356.9 m 41.5 m
  • Los Chorros Viaduct: 260.0 m 36.0 m
  • La Martorella Viaduct: 204.0 m 38.0 m
  • L´Aguilerá Viaduct: 283.0 m 38.0 m
  • Antequera railway overpass: 74.0 m 34.0 m

Description

This series of bridges for high speed railway lines is characterized by the system used to connect the prefabricated U-beams which form the bridge deck.

This connection ensures a better response of the bridge with respect to the heavy train loads. The statically determined system of the prefabricated U-beams is only supporting their self-weight. The continuity system connects these beams so to configure a continuous deck which bears the remaining permanent and live loads. The main achievements are: a better structural behavior, shorter lead times and lower costs.
